standard & specification

Tubes for heat exchanger uses,including , U bending tubes

ASTM B622 Seamless ferritic and austenitic alloy-steel boiler, superheater, and heat-exchanger tubes
A213 A213/A213M-99a Specification for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes
A249 A249/A249M-98e1 Specification for Welded Austenitic Steel Boiler, Superheater, Heat-Exchanger, and Condenser Tubes
A688/A688M-98 Specification for Welded Austenitic Stainless Steel Feedwater Heater Tubes
DIN 28180 Seamless Steel Tubes for Tubular Heat-Exchangers: Dimensions, Tolerances and Materials
NFA 49127 Seamless tubes for heat exchangers- stainless ferritc, austenitic or ferritaustenitic steel grades
BS 3606 Steel tubes for heat exchangers
ASTM B338 Seamless and welded titanium and Titanium Alloy tubes for condensers and heat exchangers
ASTM B 163 Seamless Nickel and Nickel Alloy Condenser and Heat Exchanger Tubes
A179 A179/A179M-90a (1996) e1 Specification for Seamless Cold-Drawn Low-Carbon Steel Heat-Exchanger and Condenser Tubes
A498 A498-98 Specification for Seamless and Welded Carbon, Ferritic, and Austenitic Alloy Steel Heat-Exchanger Tubes with Integral Fins
low carbon steel tubes for heat exchanger and boilers
ASTM A179, DIN17175, BS3602, NFA A49215, JIS G 3461, A192, A210 Grade A1,A210 Grade C, ASTM A556
A214, DIN17177, BS 3059, NFA A49242, JIS G3461, A226 heat exchanger tubes

Alloy steel tubes for heat exchanger and boilers
ASTM A209, T1,T1A, T1b
ASTM A199,T4,T5,T9,T11,T21,T22,T91
ASTM A213,T2, T5,T5b,T5c, T9, T11, T12, T17,T21,T22,T91,T92
ASTM A334, Grade1,3,6,7,8,91,112. DIN17173, BS3603, JIS G3464
BS3606, JIS G3462
DIN17176, BS3604

0Cr18Ni10Ti(TP 321、X6CrNiTi18-10), 0Cr18Ni9, (TP 304、X5CrNi18-10), 00Cr19Ni10,(TP 304L、X2CrNi18-9), 0Cr17Ni12Mo2, (TP 316、X5CrNiMo17-12-2), 00Cr17Ni14Mo2, (TP 316L、X2CrNiMo17-12-2), 0Cr19Ni9N(TP304N), 00Cr18Ni10N(TP 304LN), 0Cr17Ni12Mo2N(TP 316N), 00Cr17Ni13Mo2N (TP 316LN), 1Cr18Ni9Ti, 0Cr25Ni20(TP 310S), 0Cr18Ni12Mo2Ti, (X6CrNiMoTi17-12-2), 00Cr22Ni5Mo3N, (UNS S31803, S32205), GB13296, ASME SA213, ASME SA-789,EN10216-5, TP316Ti, TP317L, TP321H, TP347, TP347H, S32750, S32760, 904L, N06600, N08825, N04405,
Titanium tubes:GR1 GR2 GR3 GR7 GR9 GR12 GR16 GR17; Standards: ASTM B337, ASTM B338, ASME SB337, ASME SB338, GB/T3624-95 GB/T3625-95

Heat Exchanger Tubes
Seamless cold-finished tubes in the size range 6,0 up to 60,3 mm OD particularly in Heat exchanger and condenser tubes (pipes) dimensions can be supplied in fix- and random lengths, in straight lengths as well as in U-bend execution. seamless tubes in stainless steel, nickel alloys and titanium as mentioned are applied in Chemical industry, Petrochemical industry, Fertilizer industry, Power industry, Thermal Processing Plants and Shipbuilding Industry all over the world. Even when applied under most severe operating conditions Seamless Tubes have proved that they meet highest requirements in respect to quality, performance and resistance.

Manufacturing Standard DIN 17456 ASTM A 268 ASTM A 269 ASTM A 312 NFA 49117
TStandard: EN-ISO 1127 ASTM A 268 ASTM A 269 ASTM A 530 Average wall
  (DIN 2462)
Tubes according to these specifications must not be used as heat exchanger tubes.
Cold Finished Heat Exchanger Tubes
Manufacturing Standard DIN 17458/AD-W ASTM A 213 NFA 49217
Standard: EN-ISO 1127 ASTM A 450 Average wall
  (DIN 2462) (min. wall)
  DIN 28180   Minimum wall
Tubes according to these specifications can be used as line pipes as well.
